Framesets ELVES

ELVES Mori Aerox

Name: ELVES Mori Aerox
Brand: ELVES
Price: 996.00 USD
Availability: InStock

$996.00 USD

0 products in stock

The Elves Mori AeroX is a full-carbon aero-gravel frameset built for speed on mixed-surface terrain. Using Toray T800/T1000 carbon with EPS molding, it combines race-grade efficiency, full internal routing, T47 threaded durability, and clearance for 700×45c or 650b×50 setups. From fast gravel to loaded bikepacking, the AeroX delivers stable handling, clean integration, and proven long-range comfort.
For Custom Colour Options, conctact us and we’ll work with you to bring your vision to life
ATTENTION: When measuring the stem length for this bike, be sure to subtract 1cm from your selection, since the reference markers used by Avenger are not to the center of the handlebar.

Customer Support Our dedicated team is always here to help with sizing, builds, and orders.

Warranty Protected 5-year frame/fork, 2-year bars & wheels, 1-year saddles

Shipping Included Included on most components and wheelsets. Free on orders over $100. Worldwide delivery with tracking.

Rider Approved We test and ride what we sell. Every product is hand-selected for quality and performance.

The ELVES Mori AeroX is an aero-gravel race frameset that blends road-bike speed with true mixed-surface control. Built from Toray T800/T1000 carbon using EPS + latex bladder molding, it features a creak-resistant T47 threaded BB, full internal routing, flat-mount discs, and modern electronic/mechanical drivetrain compatibility (Di2/eTap). With clearance up to 700×45c (or 650b×50), AeroX is ready for fast gravel, endurance fondos, and bikepacking.

Elves Mori AeroX Frameset — Features & Benefits

Aero-Gravel Efficiency: Pro-leaning geometry and aero tube shaping deliver road-like speed on hardpack.
Premium Carbon Layup: Toray T800 with T1000 reinforcement for high stiffness-to-weight and precise handling.
Clean, Quiet Routing: Fully integrated cabling keeps the cockpit sleek and protected from dust/mud.
T47 Threaded BB: Serviceable, creak-resistant standard with 24 mm / DUB 28.99 / 30 mm options.
Gravel-Ready Clearance: Room for 700×45c (or 650b×50) to tune speed vs. comfort.
UDH Ecosystem: Ships with SRAM UDH hanger for broad drivetrain compatibility and easy spares.
Confident Braking: Flat-mount discs with rotor sizes up to 160 mm front & rear.
Tested for Safety: Meets EN 14766 & ISO 4210-6:2023; UCI approval pending.

Elves Mori AeroX Frameset — Specifications

Technical Specifications

Frame: Full-carbon Toray T800/T1000, EPS + latex bladder molding, pro geometry; integrated seat clamp
Bottom Bracket: T47 threaded
Routing: Fully internal; electronic & mechanical compatible (Di2/eTap)
Fork: Full-carbon; 45 mm offset; 300 mm steerer; flat-mount; max rotor 160 mm
Axles: Front M12×1.5×121 mm; Rear M12×1.5×170 mm (142 mm spacing)
Max Tire Size: 700×45c (650b×50 compatible)
Max Rotor Size: Up to 160 mm (front & rear)
Headset bearings: 1-1/2" × 8 mm lower, 1-1/2" × 7 mm upper

Frame weights (unpainted): 46 = 960 g; 49 = 990 g; 52 = 1020 g; 54 = 1050 g; 56 = 1080 g
Fork weight: 428 g (w/o thru-axle)
Seatpost weight: 188 g (12 mm offset) / 220 g (25 mm offset)
Paint weights: Single-colour 80 g; Two-tone 120 g; Three-tone 180 g
Hanger: SRAM UDH (x2 supplied)
Certifications: EN 14766 & ISO 4210-6:2023 (UCI pending)
