Name: TAVELO Arow Frameset
Brand: Tavelo Frameset
Price: 1850.00 USD
Availability: InStock

Product label: % Sale

Product label: % Sale

Customer Support Our dedicated team is always here to help with sizing, builds, and orders.

Warranty Protected UCI approved, EN ISO 4210 certified

Shipping Included Included on most components and wheelsets. Free on orders over $100. Worldwide delivery with tracking.

Rider Approved We test and ride what we sell. Every product is hand-selected for quality and performance.

The Tavelo Arow Frameset is engineered around the principle that aero is everything—developed in the wind tunnel to maximize speed while minimizing energy expenditure by reducing frontal area. A narrowed, streamlined head tube cuts drag, while the frame design balances stiffness and comfort for confident handling and all-day efficiency. With clearance for 32 mm tires, the Arow adds compliance without sacrificing race-ready responsiveness.

Through precise calculations and optimization, the Arow’s tube shapes and lay-up target low aerodynamic drag and efficient power transfer. The rear triangle is tuned for comfort and control, so the bike stays fast and forgiving on varied road surfaces. Included in your purchase, is Tavelo’s integrated AVRO GEN-1 cockpit for clean routing and enhanced aerodynamics.

Tavelo Arow Frameset Features & Benefits

Wind-Tunnel Developed: Narrowed, streamlined head tube reduces frontal surface area and drag.
Lightweight Construction: Optimized lay-up; Race (XS) ~820 g, SL (XS) ~710 g (frameset).
Ride Quality: Enhanced stiffness with a rear design tuned for comfort and precise control.
Tire Clearance: Up to 700×32 mm for added compliance and traction.
Integrated Cockpit: AVRO GEN-1 handlebar with sleek internal cable routing.

Tavelo Arow Frameset Specifications

Frame Specs

Material: Toray T800 carbon
Brake Type: Disc
Cable Routing: Fully internal
Bottom Bracket: PF-BB86 (41 mm press-fit)
Thru-Axles: 12×100 mm (front), 12×142 mm (rear)
Headset: 32.8–41.8 mm & 34.1–46.9 mm (FSA)
Seat Rail Specs: 7×7 mm (metal), 7×9 mm (carbon)
Tire Clearance: Max 700×32 mm
Compliance: EN ISO 4210:2014; UCI approved

Included with Frameset

Frame & Fork
Seatpost
Headset & Spacers
Front & Rear Thru-Axles
Saddle Clamp (alloy & carbon-rail)
Shimano-compatible 24 mm bottom bracket
Integrated AVRO GEN-1 handlebar
Warranty: 5 years

Compatibility

Gear Type: Electronic shifting
Brake Type: Disc brakes (140 mm or 160 mm rotor)
Tire Clearance: Supports up to 32 mm
Dropout Type: Modular or direct mount

Tavelo Arow Frameset Geometry

Tavelo Arow geometry diagram with labeled measurements A–K plus reach/stack — Reference: A–K, reach, stack, stand-over, fork trail.

SIZE	XS	S	M	L	XL	XXL
A	420	450	480	510	540	580
B	510	520	536	549	575	587
C	116	123.3	134.1	148.9	172.1	200.7
D	410	410	410	410	410	410
E (°)	70.8°	71.4°	72°	72.8°	73°	73°
F (°)	75°	74.5°	74°	73.5°	73°	73°
G	71	71	71	70	70	70
H	572.2	577	583.5	589.3	602	620.5
I	370	370	370	370	370	370
J	971.6	976.4	983	989.1	1001.9	1020.5
K	45	45	45	45	45	45
REACH	365	372	380	388	396	407
STACK	517	526	538	554	576	604
STAND OVER	702	727	752	779	805	841
FORK TRAIL	72.4	68.4	64.6	59.6	58.4	58.4

Compare your current bike’s reach and stack for best results.

Tavelo Avro Gen 1 Integrated Carbon Handlebar geometry reference showing A/B widths, C stem length, D outsweep, E stem angle, F stack height, plus reach and drop — Geometry reference: A/B (widths), C (stem length), D (outsweep), E (stem angle), F (stack height), Reach & Drop.

Tavelo Avro Gen 1 Integrated Carbon Handlebar Geometry & Sizes

A = Width at hoods (mm)
B = Width at drops (mm)
C = Stem length (mm)
D = Outsweep / flare (°)
E = Stem angle (°)
F = Stack height (mm)
Reach = Horizontal from tops to hoods (mm)
Drop = Vertical from tops to drops (mm)

A/B Width Options

Size label	A — Hoods (mm)	B — Drops (mm)
36	360	380
38	380	400
40	400	420
42	420	440

C — Stem Lengths

80 / 90 / 100 / 110 / 120 / 130 mm

D — Outsweep

2.6°

E — Stem Angle

10°

F — Stack Height

36.4 mm

Reach

77 mm

Drop

130 mm

Note: Drop width (B) includes the 2.6° outsweep, so it measures wider than hood width (A).
